Diatoms of North AmericaDiatoms of North America

Navicula subconcentrica

Lange-Bert. 2001

Navicula Subconcentrica Guide
  • Category
    Symmetric Biraphid
  • Length Range
    36-58 µm
  • Width Range
    8.5-10.6 µm
  • Striae in 10 µm
    10-12

Identification

Navicula subconcentrica LM7 Navicula subconcentrica LM6 Navicula subconcentrica LM5 Navicula subconcentrica LM4 Navicula subconcentrica LM3 Navicula subconcentrica LM2 Navicula subconcentrica LM1
View image metadata
Navicula subconcentrica SEM2 Navicula subconcentrica SEM1

Description

Valves are lanceolate and narrow gradually to weakly protracted acutely rounded ends, or apices narrow abruptly to form protracted, subcapitate ends. The axial area is narrow and widens gradually to a small, more or less rhombic central area. The raphe sternum and central nodule appear raised in relief. The central nodule is half again wider than the raphe sternum and has flat or occasionally concave sides. The raphe is weakly lateral and nearly straight along the valve midline. Proximal raphe ends are nearly straight and relatively close together. Raphe pores are distinct and deltoid in shape. Terminal raphe fissures are hooked, the hooks opening toward the secondary side. The striae are strongly radiate throughout and become parallel only at the poles. Areolae in the striae are distinct and number 24-27 in 10 µm.

Autecology

There are 13 records of Navicula subconcentrica in the Montana Diatom Collection, most of them from lakes and ponds in the Canadian Rockies Ecoregion (Glacier and Waterton Lakes National Parks), where it prefers alkaline waters (mean pH = 8.2) of modest conductivity (mean SC = 315 µS/cm). Common diatom associates of N. subconcentrica in the Northern Rockies are Sellaphora parapupula, Navicula schadei, Navicula wildii, Placoneis explanata, Navicula jaagii, Cymbella transilvanica, Cymbella laevis v. lata, Fragilaria capucina v. austriaca, Cymbopleura inaequalis, Encyonopsis descripta, Cymbella frigida, and Neidium apiculatum. Lange-Bertalot (2001) described this species from material collected in an oligotrophic chalk-rich lake in Bavaria.

Governor Pond And Mount Wilbur
Credit: Loren Bahls
Governor Pond, Glacier National Park, Montana: home of Navicula subconcentrica

Original Description

Valves lanceolate, gradually narrowing to weakly protracted acutely rounded ends, length 40-64 microns, breadth 9-10 microns. Raphe slightly sinuous, weakly lateral with distinct central pores in a comparatively narrow position. Axial area (very) narrow distally widening gradually to a small central area with various outlines due to some irregularly shortened median striae. Striae rather strongly radiate, some short ones in subpolar position parallel or very indistinctly convergent, 10.5-12/10 microns; lineolae arranged as in Navicula concentrica but less coarse than in that species, c. 27-29/10 microns. SEM (Fig. 30: 12): Sternum relief-like prominent on the valve outside, expanded in the centre. Central pores short, drop-like, not hooked and only slightly deflected to the secondary valve side.

  • Author
    Lange-Bert. 2001
  • Length Range
    40-64 µm
  • Width
    9-10 µm
  • Striae in 10µm
    10.5-12.0

Original Images

Navsubcon Origimag
Navsubcon Origdesc

Cite This Page

Bahls, L. (2011). Navicula subconcentrica. In Diatoms of North America. Retrieved December 16, 2024, from https://diatoms.org/species/47667/navicula_subconcentrica

Responses

The 15 response plots show an environmental variable (x axis) against the relative abundance (y axis) of Navicula subconcentrica from all the stream reaches where it was present. Note that the relative abundance scale is the same on each plot. Explanation of each environmental variable and units are as follows:

ELEVATION = stream reach elevation (meters)
STRAHLER = distribution plot of the Strahler Stream Order
SLOPE = stream reach gradient (degrees)
W1_HALL = an index that is a measure of streamside (riparian) human activity that ranges from 0 - 10, with a value of 0 indicating of minimal disturbance to a value of 10 indicating severe disturbance.
PHSTVL = pH measured in a sealed syringe sample (pH units)
log_COND = log concentration of specific conductivity (µS/cm)
log_PTL = log concentration of total phosphorus (µg/L)
log_NO3 = log concentration of nitrate (µeq/L)
log_DOC = log concentration of dissolved organic carbon (mg/L)
log_SIO2 = log concentration of silicon (mg/L)
log_NA = log concentration of sodium (µeq/L)
log_HCO3 = log concentration of the bicarbonate ion (µeq/L)
EMBED = percent of the stream substrate that is embedded by sand and fine sediment
log_TURBIDITY = log of turbidity, a measure of cloudiness of water, in nephelometric turbidity units (NTU).
DISTOT = an index of total human disturbance in the watershed that ranges from 1 - 100, with a value of 0 indicating of minimal disturbance to a value of 100 indicating severe disturbance.
