Cells are cylindrical. The valve face is concentrically undulate, with marginal striae and a central star-shaped cluster of 5 to 12 nearly triangular, punctate fields. The triangular fields lie with their pointed ends oriented toward the valve center. The open area at the center of the star varies in size with valve size and may be ornamented with a few scattered areolae. Marginal striae are slightly unequal in length and composed of very fine areolae. Every third or fourth interstria (costa) is thickened and appears in LM as the so-called shadow lines (Schattenlinien). These thicker costae number about 5 in 10 µm.
Several investigators have published SEM images and descriptions of Cyclotella antiqua (Houk et al. 2010, Kling & Håkansson 1988, Lowe 1975). External SEM views show a domed valve face with the triangular punctate fields and the valve center lying in slight depressions. Each triangular field is separated by a low unornamented ridge. The triangular fields are ornamented with areolae that are larger than those in the striae. Internally, the striae are expressed as alveoli that are presumably covered with cribra (when unaltered by dissolution). These alveoli are separated by thickened costae and are visible in LM with critical focus. Within an eroded alveolus can be seen two or three thinner costae and external openings of areolae in the striae. Internal valve views show 1-3 rimoportulae scattered between the triangular fields in the area between the central star and the marginal striae. Both central and marginal fultoportulae are present internally. One marginal fultoportula lies on each of the thickened costae. Central fultoportulae are scattered among areolae within the triangular fields. Internally, each fultoportula opens to a short central tube, on each side of which is a satellite pore.
Note that stria density of "about 17 in 10 µm" is usually repeated in the literature (Houk et al. 2010, Kling & Håkansson 1988, Krammer & Lange-Bertalot 1991); the stria density of Montana specimens ranges from 17 to 20 in 10 µm.
Houk et al. (2010) report Cyclotella antiqua as a littoral resident of lakes or pools with low pH and low conductivity in Finland, Canada, Norway, Sweden, Scotland, and Siberia. U.S. records include Alaska (Foged 1981), the Laurentian Great Lakes (Lowe 1975), and Lake Tahoe (Mahood et al. 1984). The specimens shown here are from two lakes and a stream in Glacier National Park, Montana. The stream, Camas Creek, drains a series of paternoster lakes, the lower one of which, Trout Lake, is presumably the source of the Lindavia antiqua specimen in Fig. 1. Lake McDonald in Glacier National Park has a pH of 8.7 and specific conductance of 92 µS/cm; Medicine Grizzly Lake (photo below) has a pH of 9.1 and specific conductance of 93 µS/cm.
Transferred on this website from C. antiqua to L. antiqua, following Nakov et al. (2015). - S. Spaulding
Bahls, L. (2013). Lindavia antiqua. In Diatoms of North America. Retrieved December 16, 2024, from https://diatoms.org/species/49545/lindavia_antiqua
The 15 response plots show an environmental variable (x axis) against the relative abundance (y axis) of Lindavia antiqua from all the stream reaches where it was present. Note that the relative abundance scale is the same on each plot. Explanation of each environmental variable and units are as follows:
ELEVATION = stream reach elevation (meters)
STRAHLER = distribution plot of the Strahler Stream Order
SLOPE = stream reach gradient (degrees)
W1_HALL = an index that is a measure of streamside (riparian) human activity that ranges from 0 - 10, with a value of 0 indicating of minimal disturbance to a value of 10 indicating severe disturbance.
PHSTVL = pH measured in a sealed syringe sample (pH units)
log_COND = log concentration of specific conductivity (µS/cm)
log_PTL = log concentration of total phosphorus (µg/L)
log_NO3 = log concentration of nitrate (µeq/L)
log_DOC = log concentration of dissolved organic carbon (mg/L)
log_SIO2 = log concentration of silicon (mg/L)
log_NA = log concentration of sodium (µeq/L)
log_HCO3 = log concentration of the bicarbonate ion (µeq/L)
EMBED = percent of the stream substrate that is embedded by sand and fine sediment
log_TURBIDITY = log of turbidity, a measure of cloudiness of water, in nephelometric turbidity units (NTU).
DISTOT = an index of total human disturbance in the watershed that ranges from 1 - 100, with a value of 0 indicating of minimal disturbance to a value of 100 indicating severe disturbance.
