Compare

Aulacoseira muzzanensis has generally lower mantle height to valve diameter ratio than A. granulata. If this ratio at least in some cells in a colony is less than 0.8, or if it is between 0.8 and 1.2, but areolae are coarse and disorganized, a specimen should be identified as A. muzzanensis. If this ratio in all cells is greater than 0.8, or it is between 0.8 and 1.2, but areolae are organized in regular rows, it is placed in A. granulata.

LM scalebar = 10 µm
Aulacoseira muzzanensis LM3 Aulacoseira muzzanensis LM2 Aulacoseira muzzanensis LM5 Aulacoseira muzzanensis LM4 Aulacoseira muzzanensis LM7 Aulacoseira muzzanensis LM6 Aulacoseira muzzanensis LM1
Diameter
9-24 µm
Width Range
5-13 µm
Striae in 10 µm
7-15

Aulacoseira granulata

(Ehrenb.) Simonsen 1979

Aulacoseira granulata LM1 Aulacoseira granulata LM2 Aulacoseira granulata LM3 Aulacoseira granulata LM4 Aulacoseira granulata LM5 Aulacoseira granulata LM6
Diameter
4-17 µm
Width Range
4-20 µm
Striae in 10 µm
8-18
