Compare Navicula harmoniae

Bahls 2014

Compare

Navicula sovereignii has broadly rounded apices and a round central area. Navicula sovereignii also has bulbous proximal raphe ends and vermiform markings in the axial and central areas, which are lacking in N. harmoniae. Navicula lundii is smaller with weakly protracted apices, an asymmetric central area, and striae that are weakly convergent at the apices.

LM scalebar = 10 µm
Navicula harmoniae LM1 Navicula harmoniae LM2 Navicula harmoniae LM3 Navicula harmoniae LM4 Navicula harmoniae LM5 Navicula harmoniae LM6 Navicula harmoniae LM7
Length Range
33-68 µm
Width Range
8.1-10.2 µm
Striae in 10 µm
9-13 at valve center, 13-16 near the apices

Navicula sovereignii

Bahls 2011

Navicula sovereignii LM1 Navicula sovereignii LM3 Navicula sovereignii LM2 Navicula sovereignii LM5 Navicula sovereignii LM4
Length Range
52-87 µm
Width Range
12.8-16.5 µm
Striae in 10 µm
8-10

Navicula lundii

E.Reichardt 1985

Navicula lundii LM7 Navicula lundii LM6 Navicula lundii LM5 Navicula lundii LM4 Navicula lundii LM3 Navicula lundii LM2 Navicula lundii LM1
Length Range
22-38 µm
Width Range
4.8-6.9 µm
Striae in 10 µm
14-18
