Compare Neidiopsis weilandii | Species - Diatoms of North America

Compare

Neidiopsis weilandii is larger and has more linear valves, with cuneate to subrostrate apices as compared to N. wulffii. Valves of N. vekhovii are smaller, with triundulate margins. Neidiopsis hamiltonii and N. levanderi have straight, rather than deflected, proximal raphe ends. Species in the genus Neidium have proximal raphe ends that are hooked to opposite sides of the valve.

LM scalebar = 10 µm

Neidiopsis weilandii LM3

Neidiopsis weilandii LM1

Neidiopsis weilandii LM2

Neidiopsis weilandii LM4

Neidiopsis weilandii LM5

Neidiopsis weilandii LM6

Neidiopsis weilandii LM7

Length Range
39.4-65.1 µm

Width Range
9.0-11.4 µm

Striae in 10 µm
18-20

Neidiopsis hamiltonii

Bahls 2014

Neidiopsis hamiltonii LM1

Neidiopsis hamiltonii LM2

Neidiopsis hamiltonii LM3

Neidiopsis hamiltonii LM4

Neidiopsis hamiltonii LM5

Neidiopsis hamiltonii LM6

Neidiopsis hamiltonii LM7

Length Range
19.5-43.6 µm

Width Range
6.0-8.3 µm

Striae in 10 µm
22-24

Neidiopsis levanderi

(Hust.) Lange-Bert. and Metzeltin in Lange-Bert. and Genkal 1999

Neidiopsis levanderi LM5

Neidiopsis levanderi LM4

Neidiopsis levanderi LM3

Neidiopsis levanderi LM2

Neidiopsis levanderi LM1

Length Range
27-47 µm

Width Range
6.6-8.9 µm

Striae in 10 µm
21-24

Neidiopsis wulffii

(J.B.Petersen) Lange-Bert. in Lange-Bert. and Genkal 1999

Neidiopsis wulffii LM6

Neidiopsis wulffii LM5

Neidiopsis wulffii LM4

Neidiopsis wulffii LM3

Neidiopsis wulffii LM2

Neidiopsis wulffii LM1

Length Range
39-48 µm

Width Range
9.4-11.4 µm

Striae in 10 µm
16-18

Also compare to

Neidiopsis vekhovii

Lange-Bert. and Genkal 1999
