Frustules have length to width ratios between 2 and 5. The valve face is flat, isopolar, with cuneate or occasionally capitate apices. In valves beyond 25 µm in length, the sides are straight and parallel, while under 25 µm the frustule can be elliptical. The keel is not raised and no alar wings are visible. Fibulae are present on the interior of the valve surface, 7-8 in 10 µm. Every third or fourth costa on the valve surface is either raised or lowered from the plane of the other costae. These altered costae correspond to the fibulae below the valve surface. Not infrequently, raised costae can arise in double form, where no intermediate lower costae exist. The striae, visible in the SEM, consist of 2-5 rows of areolae situated between the costae, 23-28 in 10 µm.
Potapova, M., English, J. (2010). Surirella angusta. In Diatoms of North America. Retrieved December 12, 2024, from https://diatoms.org/species/45046/surirella_angusta
The 15 response plots show an environmental variable (x axis) against the relative abundance (y axis) of Surirella angusta from all the stream reaches where it was present. Note that the relative abundance scale is the same on each plot. Explanation of each environmental variable and units are as follows:
ELEVATION = stream reach elevation (meters)
STRAHLER = distribution plot of the Strahler Stream Order
SLOPE = stream reach gradient (degrees)
W1_HALL = an index that is a measure of streamside (riparian) human activity that ranges from 0 - 10, with a value of 0 indicating of minimal disturbance to a value of 10 indicating severe disturbance.
PHSTVL = pH measured in a sealed syringe sample (pH units)
log_COND = log concentration of specific conductivity (µS/cm)
log_PTL = log concentration of total phosphorus (µg/L)
log_NO3 = log concentration of nitrate (µeq/L)
log_DOC = log concentration of dissolved organic carbon (mg/L)
log_SIO2 = log concentration of silicon (mg/L)
log_NA = log concentration of sodium (µeq/L)
log_HCO3 = log concentration of the bicarbonate ion (µeq/L)
EMBED = percent of the stream substrate that is embedded by sand and fine sediment
log_TURBIDITY = log of turbidity, a measure of cloudiness of water, in nephelometric turbidity units (NTU).
DISTOT = an index of total human disturbance in the watershed that ranges from 1 - 100, with a value of 0 indicating of minimal disturbance to a value of 100 indicating severe disturbance.
