Compare Tursiocola costata

Frankovich and M.J.Sullivan 2015

Compare

Tursiocola ziemanii is very similar and smaller specimens may not be distinguishable from T. costata. Striae are convergent in the central valve, becoming parallel near the apices.

LM scalebar = 10 µm
Tursiocola costata LM3 r Tursiocola costata LM1 r Tursiocola costata LM4 r Tursiocola costata LM5 r Tursiocola costata LM2 r
Length Range
17-29 µm
Width Range
2.5-3.9 µm
Striae in 10 µm
22-29

Tursiocola ziemanii

Frankovich and M.J.Sullivan 2015

Tursiocola ziemanii LM2 Tursiocola ziemanii LM1 Tursiocola ziemanii LM3 Tursiocola ziemanii LM4 Tursiocola ziemanii LM5
Length Range
13-61 µm
Width Range
2.0-5.2 µm
Striae in 10 µm
22-34
